Fish Weigher 18 Head Linear Combination Weigher

Fish Weigher 18 Head Linear Combination Weigher

Fish Weigher 18 Head Linear Combination Weigher
Fish Weigher 18 Head Linear Combination WeigherFish Weigher 18 Head Linear Combination WeigherFish Weigher 18 Head Linear Combination WeigherFish Weigher 18 Head Linear Combination WeigherFish Weigher 18 Head Linear Combination Weigher
CategoriesLinear combination weigher
AlbumView larger image
BrandSMART WEIGH
ModelSW-LC18
ConstructionStainless steel 304
Brushed finishStainless steel 316
FOB portZhongshan port, China
Terms of PaymentL/C, T/T
Download DOC
Update Time2020-10-21
Detail Information
Specification
Model
SW-LC18
Weighing head
18 hoppers
Weighing range
10-3000 grams
Weighing method
load cell
Speed
5-30 bags/min
Accuracy
±0.1-3.0 grams
Power supply
1.0 kW
Voltage
220 V, 50 Hz or 60 Hz; Single Phase
Drive system
Stepper Motor
Control panel
10" touch screen
Application
Beans
Frozen Meat
Frozen Fish
Vegetables
Carrots
Features

² Hopper weighing and delivery into the package, only two procedures to get less scratch on products;

² Semi auto weigher with a storage hopper for convenient feeding;

² IP65 waterproof grade, the machine can be washed by water directly, easy cleaning after daily work;

² All dimension can be customized design according to product features;

² Infinite adjustable speed on belt and hopper according to different product feature;

² Rejection system can reject overweight or underweight products;

² Optional index collating belt for feeding on a tray;

² Special heating design in the electronic box to prevent high humidity environment.

Machine Details
Tray Denester
